Full Auto Die Cutting Machine

 Technical parameters and specifications:

Model: BMY-1100 Automatic Die cutting and creasing machine

Maximum paper size:  1100X800mm

Minimum paper size:  350x450

Maximum die size:  1090X780mm

The thickness of the paper:  paper 0.12-2.0mm

                       corrugated cardboard <8mm

The weight of paper : ≥ 200 gsm

Input Stack height: 1500mm

Output Stack height: 1220mm

The precision of die-cutting: ≤ ±0.50mm

Minimum gear tooth:7mm

Maximum gear tooth:16mm

Maximum machine speed: 7000S/H

Working speed: 5200-6500S/H

Working pressure: 260T

Rated power: 20KW

Dimensions: 5900×4150×2000mm

Weight of the whole machine: 11T

 Product standard configuration and function:

Product standard configuration

* European precision manufacturing techniques Feida cardboard and corrugated 　dual-purpose. Four four to send four five suction, suction sent two. According to the deformation of the paper suction angle and height adjustment.

* bilateral push and pull dual purpose, fast and accurate switching

* fish feeding, stable and accurate

* to fine tuning mechanism for paper, without stopping the adjustment

* mechanical and electrical double sheets detector

* main pay paper without stopping switch

* configuration of high speed pneumatic clutch mechanism to make the paper feeding and die cutting automatic separation

* imported belt

* Double feeder head checking device

* unique cutting mechanism, suitable for different deformation of paper

* super wear-resistant polyurethane paper conveying wheel

* dual purpose paper table

*Paper feeding time morning and evening fine adjustment device

* equipped with a set of auxiliary tray, tray two sets

* matching with a set of pre paper mechanism

Host department

* bearing part is high strength nodular cast iron - QT500, special resin sand casting process, high strength never deformation

* Japan imported steel by special treatment of high carbon chromium steel crankshaft

* Taiwan imported super wear-resistant worm wheel, worm

* convenient and quick knife template turning device

* a strong oil supply and lubrication system, without interruption and more oil

* high precision 230 degree intermittent mechanism

*Pneumatic clutch device

* high speed rotary joint

* imported tooth row chain

*Pneumatic locking plate device

* super hardness high strength titanium aluminum alloy tooth row 5 sets

Precision pressure regulating mechanism

* attached to the tooth row of a group, a plate (optional), version of the box combination of 1 sets

Receiving paper unit

* Automatic paper feeding device

* hand by hand

Automatic lifting control system for paper collecting table

* main chain protection device

* anti back paper device

The main functions of the product

1)the machine can be implemented through the touch screen man-machine dialogue, the operator can be based on the liquid crystal display window tips, easy to rule out a variety of mechanical failure, and can read the machine a variety of technical information.The whole machine by the PLC and the encoder to monitor the operation and failure of the whole machine, the display, the protection of doors and windows have a security alarm system to protect the safety of people.

2)High speed, non intermittent delivery of paper

* this machine implements the automatic switching of the main pay paper, and does not need to stop the machine to improve the work efficiency.

* European technology high precision four suction four send feta, strong suction, to ensure the smooth conveying of high speed corrugated cardboard and

* advanced push and pull two purpose side gauge, using end face cam mechanism, wear small, high stability characteristics

* double protection Feida Superelevation Design, provides a strong guarantee for the feeding and feeding safety flying head

* paper feeder can be adjusted at any time according to the paper.

* dual-use paper, can be artificial, can also be directly on the fork lift truck

* failure occurred in the feeding process, the high speed pneumatic clutch mechanism makes the feeder part is separated from the host part stops running, the normal operation of the host, improve service life, reduce the waste. This function makes the position more convenient. Check back

3)die-cutting unit

* precise adjustment of the system, easy adjustment in the case of the machine operation

* four cubits linkage design load overweight (pendulum shaft diameter 70*240) cutting pressure, small abrasion

* variable frequency drive electric drive into the worm, the worm, make the machine running smoothly, low noise

* the power supply system ensures good lubrication of the main drive.

* use advanced PLC and man-machine interface control system, make the operation of each department to get safe and accurate monitoring

* the unique design of the side location, so that each row of rows of teeth in a positioning line

*230 degree high precision intermittent mechanism to drag the five rows of teeth in a stable operation, accurate, low noise

* adjustable front and rear positioning system, precise positioning, easy adjustment

* the scissors type die cutting, so that the machine die - cutting pressure is uniform, high pressure

* imported overload torque limiter, to avoid the damage to the machine caused by the accident, to ensure the safety of the use of the machine and personnel safety

4)Receiving paper unit

* hand - in - hand side paper in the machine operation, can be operated independently to ensure that the machine does not stop the paper.

* automatic paper feeding device, so that the paper is neatly closed.

*Through the photoelectric detection switch, the automatic upper and the lower of the paper stack can be accurately controlled.

Detail list of brand name of main parts(Automatic Die cutting and creasing machine):
